29.2 Process Reward Models and MCTS

"I give every reasoning step a score between 0 and 1. Step 4 got a 0.03, which in my professional opinion means 'this is where you divided by zero and hoped nobody would notice.'"

A Process Reward Model With a Reputation for Candor

1. Outcome Reward Models versus Process Reward Models

A graduate student submits a ten-step derivation with the correct final answer, but a sign error in step three silently cancels against a second mistake in step seven; should the proof receive full marks, and more importantly, would you even notice?

An outcome reward model (ORM) takes a complete reasoning chain and produces a single score: how likely is the final answer to be correct? Training an ORM is straightforward. Given a dataset of (problem, reasoning chain, correctness label) triples, you train a classifier on the final hidden state of the chain. The limitation is that an ORM cannot tell you where a reasoning chain went wrong. A chain that fails through a single arithmetic error and one that fails through a fundamentally flawed approach both receive the same low score.

In 2023, a team at a national laboratory traced a months-long failed replication to a single sign error buried in step six of a fourteen-step derivation; every downstream calculation had silently propagated the mistake. Outcome-level checks had rated the derivation "plausible," but no tool had flagged the exact step where things went wrong.

How PRMs Score Each Step

A process reward model (PRM) scores each step individually. Given a reasoning chain split into steps \(s_1, s_2, \ldots, s_k\), the PRM produces scores \(r_1, r_2, \ldots, r_k\), where \(r_i\) estimates the probability that step \(s_i\) is correct given the problem statement and all preceding steps. Lightman et al. (2023) demonstrated that PRM-guided search outperforms ORM-guided search on the MATH benchmark by a substantial margin, particularly on harder problems where errors compound over many steps.

A process reward model is a learned classifier, typically a transformer with a scalar head (a single linear layer that maps hidden states to one number) after each reasoning step token. It outputs a correctness probability for every intermediate step in a derivation, not just a single score for the final answer. PRMs matter because multi-step reasoning is fragile: a single flawed step early in a chain corrupts all downstream conclusions. Without per-step feedback, the system cannot distinguish a near-perfect derivation with one typo from a fundamentally broken argument. The model reads the problem statement concatenated with steps \(s_1\) through \(s_i\), and the scalar head after \(s_i\) predicts whether a correct final answer is still reachable from this prefix. Use a PRM instead of an ORM whenever your reasoning chains exceed three or four steps and you need to localize errors or guide search. For single-step classification or when step boundaries are ambiguous (free-form essays, open-ended brainstorming), an ORM or a holistic rubric is simpler and sufficient.

PRMs are especially valuable for scientific reasoning because derivations are long, with many interdependent steps. An error in an early step (a sign error in a force balance, a wrong stoichiometric coefficient, a misapplied boundary condition) propagates through all subsequent steps. A PRM can localize the error and enable targeted correction, much like the step-by-step debugging approach discussed in Chapter 19: AI Assisted Debugging.

Training a Process Reward Model

Training a PRM requires step-level labels, which are expensive to obtain from human annotators. Lightman et al. collected approximately 800,000 step-level labels from human mathematicians, a heroic annotation effort. More recent approaches use automated labeling: for each step, roll out multiple completions from that step and check whether they reach the correct final answer. Steps from which correct completions are rare are likely incorrect.

This automated approach connects directly to the concept of Monte Carlo estimation of step correctness. A rollout, in this context, is a single sampled completion of the reasoning chain from a given intermediate step all the way to a final answer:

where \(N\) completions are sampled from step \(s_i\) onward. A step with \(\hat{r}_i \approx 0\) is almost certainly wrong (completions from it never reach the right answer); a step with \(\hat{r}_i \approx 1\) is almost certainly correct (completions from it reliably succeed). In short: if you can score every step, you can pinpoint the exact moment a derivation goes off the rails and fix only that step instead of starting over.

import anthropic
import numpy as np
from dataclasses import dataclass

client = anthropic.Anthropic()

@dataclass
class ScoredStep:
    """A single reasoning step with its process reward score."""
    text: str
    score: float  # estimated probability of correctness

def split_into_steps(reasoning: str) -> list[str]:
    """Split a reasoning trace into individual steps.

    Heuristic: split on 'Step N:', numbered lines, or double newlines.
    """
    import re
    # Split on "Step N:" patterns
    parts = re.split(r'(?=Step \d+[:\.])', reasoning)
    steps = [p.strip() for p in parts if p.strip()]
    if len(steps) <= 1:
        # Fallback: split on double newlines
        steps = [p.strip() for p in reasoning.split('\n\n') if p.strip()]
    return steps

def estimate_step_scores(
    problem: str,
    steps: list[str],
    n_rollouts: int = 5,
    known_answer: float | None = None,
    tolerance: float = 0.05
) -> list[ScoredStep]:
    """Estimate process reward scores via Monte Carlo rollouts.

    For each step i, complete the reasoning from step i onward
    n_rollouts times. The score is the fraction of completions
    that reach the correct final answer.
    """
    scored = []

    for i, step in enumerate(steps):
        # Build the partial chain up to and including step i
        partial = f"Problem: {problem}\n\n"
        partial += "\n\n".join(steps[:i + 1])
        partial += "\n\nContinue solving from here. Show remaining steps and give the final numerical answer."

        correct_count = 0
        for _ in range(n_rollouts):
            response = client.messages.create(
                model="claude-sonnet-4-20250514",
                max_tokens=1024,
                temperature=0.8,
                messages=[{"role": "user", "content": partial}]
            )
            completion = response.content[0].text

            # Extract numerical answer from completion
            import re
            numbers = re.findall(
                r'[-+]?\d*\.?\d+(?:[eE][-+]?\d+)?',
                completion
            )
            if numbers and known_answer is not None:
                final = float(numbers[-1])
                if abs(final - known_answer) / max(abs(known_answer), 1e-10) < tolerance:
                    correct_count += 1

        score = correct_count / n_rollouts if known_answer is not None else 0.5
        scored.append(ScoredStep(text=step, score=score))

    return scored

# Example: score steps of a physics derivation
problem = "What is the escape velocity from Earth's surface? (M=5.97e24 kg, R=6.37e6 m, G=6.674e-11)"
known_answer = 11186.0  # m/s

# Generate a reasoning chain
response = client.messages.create(
    model="claude-sonnet-4-20250514",
    max_tokens=1024,
    messages=[{"role": "user", "content": f"Solve step by step:\n{problem}"}]
)
reasoning = response.content[0].text
steps = split_into_steps(reasoning)

# Score each step
scored_steps = estimate_step_scores(problem, steps, n_rollouts=5, known_answer=known_answer)
for i, ss in enumerate(scored_steps):
    status = "OK" if ss.score >= 0.6 else "SUSPECT"
    print(f"Step {i+1} [{status}] (score={ss.score:.2f}): {ss.text[:80]}...")

2. Monte Carlo Tree Search Over Reasoning

Scoring individual reasoning steps opens a further possibility: instead of generating a single chain and hoping it stays on track, the system can explore multiple branching paths simultaneously, letting per-step scores guide it toward the best one.

Process reward models enable a powerful generalization: treating reasoning as a tree search problem. Instead of generating a single chain and scoring it, we can explore a tree of possible reasoning paths, using the PRM to guide which branches to expand.

This is Monte Carlo Tree Search (MCTS), the algorithm that powered AlphaGo's 2016 victory over Lee Sedol. Where AlphaGo's value network scored board positions, a PRM scores partial derivations, estimating the probability of reaching a correct answer from each reasoning prefix.

The MCTS loop has four phases, illustrated in Figure 29.2 and directly analogous to the search framework introduced in Chapter 1: Discovery as Search: Figure 29.2.1 illustrates the MCTS four-phase loop over reasoning traces.

1. Selection: Starting from the root (the problem statement), traverse the tree by selecting the child node with the highest Upper Confidence Bound (UCB) score until you reach a leaf.
2. Expansion: From the leaf, generate one or more candidate next steps using the language model.
3. Evaluation: Score each candidate step using the PRM.
4. Backpropagation: Update the scores of all ancestor nodes based on the evaluation results. (Note: this is tree-score propagation, not the gradient-based backpropagation used to train neural networks; the name is shared because both pass information backward through a structure, but no gradients are involved here.)

The UCB formula balances exploitation (expanding high-scoring branches) with exploration (trying under-explored branches):

where \(\bar{r}(s)\) is the average reward of node \(s\), \(N_s\) is its visit count, \(N_{\text{parent}}\) is the parent's visit count, and \(c\) is an exploration constant (typically \(\sqrt{2}\)).

import math
from dataclasses import dataclass, field
from typing import Optional

@dataclass
class ReasoningNode:
    """A node in the reasoning tree."""
    step_text: str
    parent: Optional['ReasoningNode'] = None
    children: list['ReasoningNode'] = field(default_factory=list)
    visits: int = 0
    total_reward: float = 0.0
    prm_score: float = 0.0  # process reward for this step
    is_terminal: bool = False

    @property
    def mean_reward(self) -> float:
        return self.total_reward / max(self.visits, 1)

    def ucb(self, exploration_constant: float = 1.41) -> float:
        """Upper Confidence Bound for tree search."""
        if self.visits == 0:
            return float('inf')  # unexplored nodes have highest priority
        parent_visits = self.parent.visits if self.parent else 1
        exploitation = self.mean_reward
        exploration = exploration_constant * math.sqrt(
            math.log(parent_visits) / self.visits
        )
        return exploitation + exploration

    def get_chain(self) -> list[str]:
        """Reconstruct the full reasoning chain from root to this node."""
        chain = []
        node = self
        while node.parent is not None:
            chain.append(node.step_text)
            node = node.parent
        return list(reversed(chain))


class ReasoningMCTS:
    """Monte Carlo Tree Search over reasoning traces.

    Uses a language model to generate candidate steps and a
    process reward model (approximated by rollout) to evaluate them.
    """

    def __init__(
        self,
        client: anthropic.Anthropic,
        problem: str,
        known_answer: float | None = None,
        max_steps: int = 8,
        n_candidates: int = 3,




        exploration_c: float = 1.41
    ):
        self.client = client
        self.problem = problem
        self.known_answer = known_answer
        self.max_steps = max_steps
        self.n_candidates = n_candidates
        self.exploration_c = exploration_c
        self.root = ReasoningNode(step_text=f"Problem: {problem}")

    def select(self, node: ReasoningNode) -> ReasoningNode:
        """Select a leaf node by following highest-UCB children."""
        while node.children and not node.is_terminal:
            node = max(node.children, key=lambda c: c.ucb(self.exploration_c))
        return node

    def expand(self, node: ReasoningNode) -> list[ReasoningNode]:
        """Generate candidate next steps from a leaf node."""
        chain = node.get_chain()
        chain_text = "\n".join(chain) if chain else self.problem

        prompt = (
            f"{chain_text}\n\n"
            f"Generate the next single reasoning step. "
            f"Be specific and show calculations. "
            f"Write ONLY one step, not the full solution."
        )

        children = []
        for _ in range(self.n_candidates):
            response = self.client.messages.create(
                model="claude-sonnet-4-20250514",
                max_tokens=300,
                temperature=0.9,  # high temperature for diversity
                messages=[{"role": "user", "content": prompt}]
            )
            step_text = response.content[0].text.strip()
            child = ReasoningNode(step_text=step_text, parent=node)

            # Check if this step contains a final answer
            if any(marker in step_text.lower() for marker in
                   ["therefore", "final answer", "the answer is", "= "]):
                depth = len(child.get_chain())
                if depth >= 3:  # at least 3 steps before terminating
                    child.is_terminal = True

            children.append(child)

        node.children = children
        return children

    def evaluate(self, node: ReasoningNode, n_rollouts: int = 3) -> float:
        """Evaluate a node by rolling out completions and checking answers."""
        chain = node.get_chain()
        chain_text = "\n".join(chain)

        if self.known_answer is None:
            return 0.5  # no ground truth available

        correct = 0
        for _ in range(n_rollouts):
            prompt = (
                f"Problem: {self.problem}\n\n"
                f"Partial solution:\n{chain_text}\n\n"
                f"Complete the solution. Give a final numerical answer."
            )
            response = self.client.messages.create(
                model="claude-sonnet-4-20250514",
                max_tokens=512,
                temperature=0.5,
                messages=[{"role": "user", "content": prompt}]
            )
            import re
            numbers = re.findall(
                r'[-+]?\d*\.?\d+(?:[eE][-+]?\d+)?',
                response.content[0].text
            )
            if numbers:
                final = float(numbers[-1])
                if abs(final - self.known_answer) / max(abs(self.known_answer), 1e-10) < 0.05:
                    correct += 1

        return correct / n_rollouts

    def backpropagate(self, node: ReasoningNode, reward: float):
        """Propagate reward up to the root."""
        while node is not None:
            node.visits += 1
            node.total_reward += reward
            node = node.parent

    def search(self, n_iterations: int = 20) -> list[str]:
        """Run MCTS and return the best reasoning chain found."""
        for _ in range(n_iterations):
            # 1. Select
            leaf = self.select(self.root)

            # 2. Expand (if not terminal and not too deep)
            if not leaf.is_terminal and len(leaf.get_chain()) < self.max_steps:
                children = self.expand(leaf)
                leaf = children[0]  # evaluate first child

            # 3. Evaluate
            reward = self.evaluate(leaf)
            leaf.prm_score = reward

            # 4. Backpropagate
            self.backpropagate(leaf, reward)

        # Return the chain with highest mean reward among terminal nodes
        best = self._best_terminal(self.root)
        return best.get_chain() if best else []

    def _best_terminal(self, node: ReasoningNode) -> Optional[ReasoningNode]:
        """Find the terminal node with highest mean reward."""
        if node.is_terminal and node.visits > 0:
            return node
        best = None
        for child in node.children:
            candidate = self._best_terminal(child)
            if candidate and (best is None or candidate.mean_reward > best.mean_reward):
                best = candidate
        return best

# Usage
mcts = ReasoningMCTS(
    client=client,
    problem="Find the minimum value of f(x) = x^2 + 2/x for x > 0.",
    known_answer=3.0,  # minimum at x = 1, f(1) = 3... actually x=1, f=3
    max_steps=6,
    n_candidates=3
)
best_chain = mcts.search(n_iterations=15)
print("Best reasoning chain found:")
for i, step in enumerate(best_chain):
    print(f"\nStep {i+1}: {step}")

3. The GPQA Diamond Benchmark

MCTS and PRM-guided search promise better reasoning, but measuring that improvement requires benchmarks where memorization cannot substitute for genuine multi-step thought.

How do we know reasoning models actually reason, rather than just recalling memorized solutions? The GPQA (Graduate-level Google-Proof Q&A) benchmark, introduced by Rein et al. (2023), was designed to answer this question. It contains graduate-level science questions written by domain experts and validated to be resistant to web search: even with unrestricted internet access, non-expert humans score only ~34% on the "Diamond" subset (the hardest tier).

The GPQA Diamond trajectory tells a compelling story about reasoning model progress:

As of mid-2025, several newer systems have posted GPQA Diamond scores in the 70%+ range, including DeepSeek-R1 (~71%), Gemini 2.5 Pro (~84%), and Claude 3.7 Sonnet (~77%), confirming that the reasoning-model approach generalizes across providers. The jump from GPT-4's ~39% to o3's ~88% reflects the impact of test-time compute scaling. Standard models improved gradually (39% to 53% over 14 months); reasoning models leapt past human expert performance in a single generation. This trajectory suggests that for well-defined scientific reasoning (where correctness is verifiable), the primary bottleneck may be shifting from model knowledge to model reasoning procedure, though contamination of training data with benchmark-similar problems remains an alternative explanation for some of the gains.

4. From MCTS to AlphaProof

DeepMind's AlphaProof system, which achieved silver-medal-level performance at the 2024 International Mathematical Olympiad, represents the most ambitious application of MCTS to mathematical reasoning. AlphaProof combines three components:

1. A language model that generates candidate proof steps in Lean 4, a formal proof language in which every mathematical statement is expressed as a type and every proof is a program that the compiler can mechanically verify.
2. The Lean 4 type checker, where a type checker is a compiler component that accepts or rejects each proof step based on whether it satisfies the formal rules of the logic, providing ground-truth verification with no ambiguity.
3. MCTS guided by a learned value function that estimates the probability of completing a proof from any partial state.

The critical insight is that Lean 4 provides a perfect process reward signal. Unlike the approximate PRM scores we computed above (which require statistical estimation via rollouts), the Lean type checker gives an exact binary signal: is this step valid? This eliminates the "hallucinated correctness" problem that plagues natural-language reasoning. A step that type-checks is correct relative to the formal axioms and definitions in scope (it guarantees logical validity within that formal system, though the formalization itself may not perfectly capture the intended mathematical statement).

AlphaProof's search tree exploration is reminiscent of AlphaZero's approach to chess and Go, but with a crucial difference: the "game" of mathematical proof has no fixed opponent and no fixed branching factor (the number of possible next moves or proof steps from any given state). A proof step might have 3 plausible continuations or 3,000. The value function must learn not just which steps are correct but which correct steps are likely to lead to a completed proof. This deeper integration of search and verification is explored further in Section 29.3.

5. Implementing a Lightweight PRM Scorer

AlphaProof's success depends on a dedicated formal verifier and months of reinforcement learning, but many scientific workflows need step-level feedback without that infrastructure.

For practitioners who need step-level scoring without training a dedicated PRM, the following pattern uses a strong language model as an approximate PRM. The model is prompted to evaluate each step against explicit correctness criteria:

def llm_as_prm(
    client: anthropic.Anthropic,
    problem: str,
    steps: list[str],
    domain: str = "mathematics"
) -> list[ScoredStep]:
    """Use a language model as an approximate process reward model.

    Scores each reasoning step on correctness, relevance, and rigor
    using structured prompting with explicit evaluation criteria.
    """
    scored_steps = []

    for i, step in enumerate(steps):
        preceding = "\n".join(steps[:i]) if i > 0 else "(start of derivation)"

        prompt = f"""You are evaluating step {i+1} of a {domain} derivation.

Problem: {problem}

Preceding steps:
{preceding}

Step to evaluate:
{step}

Evaluate this step on three criteria. For each, give a score from 0.0 to 1.0:
1. CORRECTNESS: Is the mathematical/logical content correct? Are calculations right?
2. RELEVANCE: Does this step advance toward solving the problem?
3. RIGOR: Are assumptions stated? Are approximations justified?

Respond in exactly this format:
CORRECTNESS: [score]
RELEVANCE: [score]
RIGOR: [score]
ISSUES: [brief description of any problems, or "none"]"""

        response = client.messages.create(
            model="claude-sonnet-4-20250514",
            max_tokens=200,
            temperature=0.0,  # deterministic for evaluation
            messages=[{"role": "user", "content": prompt}]
        )

        # Parse scores from response
        import re
        text = response.content[0].text
        scores = re.findall(r'(?:CORRECTNESS|RELEVANCE|RIGOR):\s*([\d.]+)', text)
        if len(scores) == 3:
            correctness, relevance, rigor = [float(s) for s in scores]
            # Weighted combination emphasizing correctness
            composite = 0.6 * correctness + 0.25 * relevance + 0.15 * rigor
        else:
            composite = 0.5  # fallback if parsing fails

        scored_steps.append(ScoredStep(text=step, score=composite))

    return scored_steps

# Example: evaluate a multi-step derivation
steps = [
    "Step 1: To find the minimum of f(x) = x^2 + 2/x for x > 0, take the derivative.",
    "Step 2: f'(x) = 2x - 2/x^2. Set f'(x) = 0.",
    "Step 3: 2x = 2/x^2, so x^3 = 1, giving x = 1.",
    "Step 4: f''(x) = 2 + 4/x^3. At x=1, f''(1) = 6 > 0, confirming a minimum.",
    "Step 5: f(1) = 1 + 2 = 3. The minimum value is 3."
]

scored = llm_as_prm(
    client,
    "Find the minimum value of f(x) = x^2 + 2/x for x > 0.",
    steps
)
for i, ss in enumerate(scored):
    bar = "#" * int(ss.score * 20)
    print(f"Step {i+1}: {ss.score:.2f} [{bar}] {ss.text[:60]}...")

Exercises

1. (Conceptual) Explain why a process reward model trained on mathematical reasoning might not transfer well to evaluating experimental design reasoning. What properties of mathematical proofs make step-level evaluation tractable that experimental reasoning lacks?
2. (Coding) Modify the ReasoningMCTS class to implement beam search instead of UCB-based tree search. At each depth level, keep the top-\(k\) steps by PRM score and expand only those. Compare the beam search and MCTS approaches on 5 optimization problems. Which finds better solutions? Which uses fewer API calls?
3. (Analysis) The GPQA Diamond trajectory shows reasoning models surpassing expert humans at ~82%. Research and discuss: does this mean the models truly "understand" graduate-level science, or could it reflect memorization of similar problems from training data? What experimental design would distinguish these hypotheses? (Hint: consider the methodology used by Rein et al. to make questions "Google-proof.")
