54.3 Building a Research Team with Review

1. Architecture Overview

What if a research team could propose a hypothesis, design the experiment, run it, peer-review the results, and revise the whole cycle in under ten minutes? A six-stage discovery pipeline achieves exactly that by connecting agents with conditional edges. The flow is not strictly sequential. The review stage can loop back to the proposer for major revisions or to the implementer for experimental redesign, and the judge controls every routing decision.

Without a routing mechanism that feeds reviewer objections back into hypothesis generation, pipelines produce results in a single pass and every flawed hypothesis reaches the output unchallenged. Teams that skip this feedback loop typically find that a large fraction of their accepted outputs are wrong (in our ablation experiments below, 70% of unreviewed hypotheses failed validation), wasting months of downstream validation effort.

The mechanism that makes this looping possible is the conditional edge.

A conditional edge is a routing rule attached to a graph node. It inspects the current state after that node finishes and selects which node runs next. Conditional edges let the pipeline make data-dependent decisions at runtime. Instead of following a fixed sequence, the graph branches based on content: a judge's verdict, a budget counter, or an error flag. LangGraph calls a Python function you supply, passes it the current state dictionary, and uses the returned string to look up the next node in a routing table. Use conditional edges whenever the next step depends on the current step's output. Use fixed edges when the sequence is unconditional. In short: conditional edges turn a linear assembly line into a learning loop, letting the pipeline revise its own mistakes before they reach the output.

Figure 54.2 illustrates the full pipeline topology, including both revision loops and the budget and iteration guards that prevent runaway cycles.

The pipeline processes hypotheses one at a time through the following stages:

1. Propose: the proposer generates a candidate hypothesis from the research question and background literature.
2. Implement: the implementer translates the hypothesis into an executable experiment plan with code, data requirements, and success criteria.
3. Experiment: the experimenter executes the experiment plan, collects results, and computes statistical summaries.
4. Review: two independent reviewers evaluate the hypothesis, experimental design, and results in parallel (round-robin protocol from Section 54.2).
5. Judge: the judge aggregates reviews, resolves disagreements, and issues a verdict (accept, major revision, minor revision, reject).
6. Route: based on the verdict, the pipeline either accepts the hypothesis (terminating), routes back for revision (looping), or rejects and moves to the next hypothesis.

"""Multi-agent discovery pipeline with LangGraph.

This module defines a six-agent discovery team as a LangGraph
StateGraph. The pipeline processes hypotheses through proposal,
implementation, experimentation, review, and judgment, with
conditional routing for revision loops.

Requirements:
    pip install langgraph langchain-core langchain-anthropic
    pip install langchain-openai numpy
"""

from __future__ import annotations

import json
import operator
from dataclasses import dataclass, field
from typing import Annotated, Any, Literal, TypedDict

from langgraph.graph import StateGraph, END


# ---------- Typed State ----------

class DiscoveryPipelineState(TypedDict):
    """Shared state for the discovery pipeline.

    LangGraph manages this state across all nodes. Each node
    reads what it needs and writes its outputs. The Annotated
    fields with operator.add use reducer semantics: new items
    are appended rather than replacing the list.
    """
    # Inputs
    research_question: str
    background: str
    available_datasets: list[str]

    # Pipeline outputs (accumulated across iterations)
    hypotheses: Annotated[list[dict], operator.add]
    experiment_plans: Annotated[list[dict], operator.add]
    experiment_results: Annotated[list[dict], operator.add]
    reviews: Annotated[list[dict], operator.add]
    judge_decisions: Annotated[list[dict], operator.add]

    # Current working hypothesis (overwritten each iteration)
    current_hypothesis: dict
    current_plan: dict
    current_result: dict
    current_reviews: list[dict]
    current_decision: dict

    # Control flow
    iteration: int
    max_iterations: int
    total_tokens: int
    token_budget: int
    status: str  # "running", "accepted", "rejected", "budget_exceeded"

2. Defining Agent Nodes

Each agent role becomes a LangGraph node: a function that takes the current state, calls a large language model (LLM) with the appropriate system prompt, and returns a state update. We use LangChain's chat model abstraction so you can swap model providers (Anthropic, OpenAI, Google) by changing a single configuration line.

from langchain_core.messages import SystemMessage, HumanMessage


def make_agent_caller(
    model_name: str,
    system_prompt: str,
    temperature: float = 0.7,
):
    """Create a reusable LLM caller with a fixed system prompt.

    Returns a callable that takes a user message string and
    returns the model's response text plus token usage.
    """
    from langchain_anthropic import ChatAnthropic
    from langchain_openai import ChatOpenAI

    if "claude" in model_name.lower():
        llm = ChatAnthropic(
            model=model_name,
            temperature=temperature,
            max_tokens=4096,
        )
    else:
        llm = ChatOpenAI(
            model=model_name,
            temperature=temperature,
            max_tokens=4096,
        )

    async def call(user_message: str) -> tuple[str, int]:
        messages = [
            SystemMessage(content=system_prompt),
            HumanMessage(content=user_message),
        ]
        response = await llm.ainvoke(messages)
        tokens = response.usage_metadata.get("total_tokens", 0)
        return response.content, tokens

    return call


# ---------- Node: Proposer ----------

async def propose_node(state: DiscoveryPipelineState) -> dict:
    """Generate a hypothesis from the research question."""
    proposer = make_agent_caller(
        model_name="claude-sonnet-4-20250514",
        system_prompt=(
            "You are a creative scientific researcher. Generate a "
            "bold, testable hypothesis that addresses the research "
            "question. Output valid JSON with keys: statement, "
            "mechanism, predictions (list), novelty_claim, "
            "required_data (list), confidence (float 0-1), "
            "risk_level (incremental/moderate/high)."
        ),
        temperature=0.9,
    )

    prompt = (
        f"Research question: {state['research_question']}\n\n"
        f"Background: {state['background']}\n\n"
        f"Available datasets: {state['available_datasets']}\n\n"
    )

    # If this is a revision, include the judge's feedback
    if state.get("current_decision", {}).get("final_decision") == "major_revision":
        feedback = state["current_decision"].get("revision_guidance", "")
        prompt += (
            f"REVISION REQUESTED. Previous hypothesis was sent back "
            f"with this feedback:\n{feedback}\n\n"
            f"Generate an improved hypothesis that addresses these concerns."
        )

    response_text, tokens = await proposer(prompt)

    hypothesis = json.loads(response_text)
    hypothesis["iteration"] = state["iteration"]

    return {
        "current_hypothesis": hypothesis,
        "hypotheses": [hypothesis],
        "total_tokens": state["total_tokens"] + tokens,
    }


# ---------- Node: Implementer ----------

async def implement_node(state: DiscoveryPipelineState) -> dict:
    """Translate a hypothesis into an executable experiment."""
    implementer = make_agent_caller(
        model_name="claude-sonnet-4-20250514",
        system_prompt=(
            "You are a meticulous computational scientist. Given a "
            "hypothesis, write a complete Python experiment to test "
            "it. Output valid JSON with keys: code (string of Python), "
            "statistical_tests (list), success_criteria (list), "
            "expected_runtime (string). The code must set random "
            "seeds and be fully self-contained."
        ),
        temperature=0.2,
    )

    hypothesis = state["current_hypothesis"]
    prompt = (
        f"Hypothesis: {hypothesis['statement']}\n"
        f"Mechanism: {hypothesis['mechanism']}\n"
        f"Predictions: {hypothesis['predictions']}\n"
        f"Required data: {hypothesis['required_data']}\n"
        f"Available datasets: {state['available_datasets']}\n\n"
        f"Write a self-contained Python experiment to test this."
    )

    response_text, tokens = await implementer(prompt)
    plan = json.loads(response_text)
    plan["hypothesis_statement"] = hypothesis["statement"]

    return {
        "current_plan": plan,
        "experiment_plans": [plan],
        "total_tokens": state["total_tokens"] + tokens,
    }


# ---------- Node: Experimenter ----------

async def experiment_node(state: DiscoveryPipelineState) -> dict:
    """Execute the experiment and collect results."""
    experimenter = make_agent_caller(
        model_name="claude-sonnet-4-20250514",
        system_prompt=(
            "You are a careful experimental scientist. Execute the "
            "provided experiment plan. Simulate running the code and "
            "report realistic results. Output valid JSON with keys: "
            "status (success/failure/error), statistical_summary "
            "(dict of test results with p_values), "
            "success_criteria_met (dict of criterion: bool), "
            "anomalies (list), interpretation (string)."
        ),
        temperature=0.1,
    )

    plan = state["current_plan"]
    prompt = (
        f"Execute this experiment:\n\n"
        f"Code:\n{plan.get('code', 'No code provided')}\n\n"
        f"Statistical tests to run: {plan.get('statistical_tests', [])}\n"
        f"Success criteria: {plan.get('success_criteria', [])}\n\n"
        f"Report all results honestly, including negative findings."
    )

    response_text, tokens = await experimenter(prompt)
    result = json.loads(response_text)
    result["hypothesis_statement"] = state["current_hypothesis"]["statement"]

    return {
        "current_result": result,
        "experiment_results": [result],
        "total_tokens": state["total_tokens"] + tokens,
    }

3. The Review and Judge Nodes

The review node runs two independent reviewers in parallel using the round-robin protocol from Section 54.2. The judge node aggregates their verdicts and decides the routing.

import asyncio


# ---------- Node: Parallel Review ----------

async def review_node(state: DiscoveryPipelineState) -> dict:
    """Run two independent reviewers in parallel."""

    reviewer_configs = [
        {
            "focus": "methodology and experimental design",
            "model": "claude-sonnet-4-20250514",
            "temperature": 0.4,
        },
        {
            "focus": "statistical rigor and reproducibility",
            "model": "gpt-4o",
            "temperature": 0.3,
        },
    ]

    async def run_single_review(config: dict) -> tuple[dict, int]:
        reviewer = make_agent_caller(
            model_name=config["model"],
            system_prompt=(
                f"You are a demanding scientific peer reviewer "
                f"specializing in {config['focus']}. Evaluate the "
                f"hypothesis, experimental design, and results. "
                f"Output valid JSON with keys: decision "
                f"(accept/revise/reject), confidence (float 0-1), "
                f"strengths (list), weaknesses (list), "
                f"methodology_score (1-10), statistical_rigor_score "
                f"(1-10), novelty_score (1-10), "
                f"reproducibility_score (1-10), overall_score (1-10), "
                f"suggested_experiments (list)."
            ),
            temperature=config["temperature"],
        )

        hypothesis = state["current_hypothesis"]
        result = state["current_result"]

        prompt = (
            f"HYPOTHESIS:\n{hypothesis['statement']}\n"
            f"Mechanism: {hypothesis['mechanism']}\n"
            f"Predictions: {hypothesis['predictions']}\n\n"
            f"EXPERIMENTAL RESULTS:\n"
            f"Status: {result.get('status', 'unknown')}\n"
            f"Statistical summary: "
            f"{json.dumps(result.get('statistical_summary', {}), indent=2)}\n"
            f"Success criteria met: "
            f"{json.dumps(result.get('success_criteria_met', {}))}\n"
            f"Anomalies: {result.get('anomalies', [])}\n"
            f"Interpretation: {result.get('interpretation', '')}\n\n"
            f"Provide your review. Be rigorous but constructive."
        )

        response_text, tokens = await reviewer(prompt)
        review = json.loads(response_text)
        review["focus"] = config["focus"]
        review["model"] = config["model"]
        return review, tokens

    # Run both reviewers in parallel
    results = await asyncio.gather(
        *[run_single_review(cfg) for cfg in reviewer_configs]
    )

    reviews = [r[0] for r in results]
    total_review_tokens = sum(r[1] for r in results)

    return {
        "current_reviews": reviews,
        "reviews": reviews,
        "total_tokens": state["total_tokens"] + total_review_tokens,
    }


# ---------- Node: Judge ----------

async def judge_node(state: DiscoveryPipelineState) -> dict:
    """Aggregate reviews and issue a final verdict."""
    judge = make_agent_caller(
        model_name="claude-sonnet-4-20250514",
        system_prompt=(
            "You are the area chair of a scientific review process. "
            "You have received multiple reviewer reports. Weigh the "
            "opinions, resolve disagreements, and make a final "
            "decision. Output valid JSON with keys: final_decision "
            "(accept/major_revision/minor_revision/reject), "
            "reasoning (string), key_concerns (list), "
            "revision_guidance (string), reviewer_agreement (float)."
        ),
        temperature=0.3,
    )

    reviews = state["current_reviews"]
    hypothesis = state["current_hypothesis"]

    prompt = (
        f"HYPOTHESIS: {hypothesis['statement']}\n\n"
        f"REVIEWER REPORTS:\n"
    )
    for i, review in enumerate(reviews, 1):
        prompt += (
            f"\nReviewer {i} ({review.get('focus', 'general')}):\n"
            f"  Decision: {review.get('decision', 'unknown')}\n"
            f"  Confidence: {review.get('confidence', 'unknown')}\n"
            f"  Strengths: {review.get('strengths', [])}\n"
            f"  Weaknesses: {review.get('weaknesses', [])}\n"
            f"  Scores: methodology={review.get('methodology_score')}, "
            f"stats={review.get('statistical_rigor_score')}, "
            f"novelty={review.get('novelty_score')}, "
            f"reproducibility={review.get('reproducibility_score')}, "
            f"overall={review.get('overall_score')}\n"
        )

    prompt += (
        f"\nIteration: {state['iteration']} of {state['max_iterations']}\n"
        f"Token budget remaining: "
        f"{state['token_budget'] - state['total_tokens']}\n\n"
        f"Make your decision. If recommending revision, provide "
        f"specific, actionable guidance."
    )

    response_text, tokens = await judge(prompt)
    decision = json.loads(response_text)
    decision["hypothesis_statement"] = hypothesis["statement"]
    decision["iteration"] = state["iteration"]

    return {
        "current_decision": decision,
        "judge_decisions": [decision],
        "total_tokens": state["total_tokens"] + tokens,
    }

4. Wiring the Graph

With all nodes defined, we wire them into a LangGraph StateGraph with conditional edges. The routing function after the judge node implements the revision loop (shown in Figure 54.2): accept terminates the pipeline, major revision loops back to the proposer, minor revision loops back to the implementer, and reject terminates with a rejection status.

def route_after_judge(state: DiscoveryPipelineState) -> str:
    """Determine the next node based on judge's verdict.

    Returns the name of the next node to execute, or END
    to terminate the pipeline.
    """
    decision = state["current_decision"]["final_decision"]
    iteration = state["iteration"]
    max_iter = state["max_iterations"]

    # Budget check
    if state["total_tokens"] >= state["token_budget"]:
        return "finalize"

    # Iteration check
    if iteration >= max_iter:
        return "finalize"

    if decision == "accept":
        return "finalize"
    elif decision == "major_revision":
        return "propose"  # Back to hypothesis generation
    elif decision == "minor_revision":
        return "implement"  # Redo the experiment only
    else:  # reject
        return "finalize"


def increment_iteration(state: DiscoveryPipelineState) -> dict:
    """Increment the iteration counter before re-entering the loop."""
    return {"iteration": state["iteration"] + 1}


def finalize_node(state: DiscoveryPipelineState) -> dict:
    """Set final status based on the last judge decision."""
    decision = state.get("current_decision", {})
    final = decision.get("final_decision", "unknown")

    if final == "accept":
        status = "accepted"
    elif state["total_tokens"] >= state["token_budget"]:
        status = "budget_exceeded"
    elif state["iteration"] >= state["max_iterations"]:
        status = "max_iterations_reached"
    else:
        status = "rejected"

    return {"status": status}


def build_discovery_pipeline() -> StateGraph:
    """Construct the full discovery pipeline as a LangGraph.

    Graph topology:
        propose -> implement -> experiment -> review -> judge
            ^           ^                                 |
            |           |_____ minor_revision ____________|
            |_____ major_revision ________________________|
                                                          |
                                        accept/reject --> finalize --> END
    """
    graph = StateGraph(DiscoveryPipelineState)

    # Add all nodes
    graph.add_node("propose", propose_node)
    graph.add_node("increment", increment_iteration)
    graph.add_node("implement", implement_node)
    graph.add_node("experiment", experiment_node)
    graph.add_node("review", review_node)
    graph.add_node("judge", judge_node)
    graph.add_node("finalize", finalize_node)

    # Sequential edges: propose -> implement -> experiment -> review -> judge
    graph.add_edge("propose", "implement")
    graph.add_edge("implement", "experiment")
    graph.add_edge("experiment", "review")
    graph.add_edge("review", "judge")

    # Conditional routing after judge
    graph.add_conditional_edges(
        "judge",
        route_after_judge,
        {
            "propose": "increment",   # Major revision: re-propose
            "implement": "increment", # Minor revision: re-implement
            "finalize": "finalize",   # Accept or reject: done
        },
    )

    # Increment loops back to the appropriate node
    # (LangGraph handles this via the routing above)
    graph.add_edge("increment", "propose")

    # Finalize leads to END
    graph.add_edge("finalize", END)

    # Set entry point
    graph.set_entry_point("propose")

    return graph


# Compile and run
pipeline = build_discovery_pipeline()
compiled = pipeline.compile()

5. Running the Pipeline

We run the pipeline on a concrete scientific task: discovering statistical relationships in the Iris dataset (a deliberate toy example so you can verify results by hand before scaling to real research problems).

import asyncio


async def run_discovery_experiment():
    """Run the multi-agent discovery pipeline on a sample task."""
    initial_state: DiscoveryPipelineState = {
        "research_question": (
            "What are the strongest predictive relationships between "
            "morphological features in the Iris dataset? Specifically, "
            "can we identify non-obvious feature interactions that "
            "improve classification accuracy beyond single-feature "
            "baselines?"
        ),
        "background": (
            "The Iris dataset contains 150 samples of three species "
            "(setosa, versicolor, virginica) with four features: "
            "sepal length, sepal width, petal length, petal width. "
            "Linear discriminant analysis achieves ~98% accuracy. "
            "We seek non-linear feature interactions that provide "
            "additional discriminative power or biological insight."
        ),
        "available_datasets": ["sklearn.datasets.load_iris"],

        # Initialize empty accumulator lists
        "hypotheses": [],
        "experiment_plans": [],
        "experiment_results": [],
        "reviews": [],
        "judge_decisions": [],

        # Current working state
        "current_hypothesis": {},
        "current_plan": {},
        "current_result": {},
        "current_reviews": [],
        "current_decision": {},

        # Control flow
        "iteration": 0,
        "max_iterations": 3,
        "total_tokens": 0,
        "token_budget": 100_000,
        "status": "running",
    }

    # Run with streaming to observe each step
    final_state = None
    async for event in compiled.astream(
        initial_state,
        config={"recursion_limit": 25},
    ):
        for node_name, node_output in event.items():
            tokens = node_output.get("total_tokens", 0)
            print(f"  [{node_name}] tokens so far: {tokens}")

            if node_name == "propose":
                h = node_output.get("current_hypothesis", {})
                print(f"    Hypothesis: {h.get('statement', '?')[:80]}")
            elif node_name == "judge":
                d = node_output.get("current_decision", {})
                print(f"    Verdict: {d.get('final_decision', '?')}")
            elif node_name == "finalize":
                print(f"    Final status: {node_output.get('status')}")

            final_state = node_output

    return final_state


# Execute
# result = asyncio.run(run_discovery_experiment())

6. Measuring Review Impact

The central empirical question of this chapter: does adding reviewers actually improve discovery quality? We answer this with an ablation study, where an ablation study is a controlled experiment that removes one component at a time to measure its individual contribution to overall performance. The study compares the full pipeline (with review) against a baseline pipeline (without review), following the controlled experiment methodology.

from dataclasses import dataclass
import numpy as np


@dataclass
class AblationResult:
    """Results from a review ablation experiment."""
    condition: str           # "full_review", "no_review", "single_reviewer"
    n_hypotheses: int        # Total hypotheses generated
    n_accepted: int          # Hypotheses that passed review (or all, if no review)
    n_correct: int           # Accepted hypotheses validated as correct
    precision: float         # n_correct / n_accepted
    total_cost: float        # Total API cost ($)
    cost_per_correct: float  # total_cost / n_correct
    avg_iterations: float    # Mean revision rounds per hypothesis
    total_tokens: int        # Total tokens consumed


async def run_ablation_study(
    research_questions: list[str],
    n_trials: int = 20,
) -> list[AblationResult]:
    """Compare discovery quality across review conditions.

    Conditions:
      1. full_review: 2 reviewers + judge (the full pipeline)
      2. single_reviewer: 1 reviewer + judge
      3. no_review: proposer -> implementer -> experimenter only

    For each condition, we run n_trials hypotheses and measure
    precision (fraction correct among accepted) and cost efficiency.
    """
    conditions = ["full_review", "single_reviewer", "no_review"]
    results = []

    for condition in conditions:
        accepted = []
        total_tokens = 0
        total_iterations = 0

        for trial in range(n_trials):
            question = research_questions[trial % len(research_questions)]

            if condition == "no_review":
                # Run without review: every hypothesis is "accepted"
                state = await run_pipeline_without_review(question)
                accepted.append({
                    "hypothesis": state["current_hypothesis"],
                    "result": state["current_result"],
                    "accepted": True,
                })
                total_tokens += state["total_tokens"]

            elif condition == "single_reviewer":
                # Run with one reviewer instead of two
                state = await run_pipeline_single_reviewer(question)
                if state["status"] == "accepted":
                    accepted.append({
                        "hypothesis": state["current_hypothesis"],
                        "result": state["current_result"],
                        "accepted": True,
                    })
                total_tokens += state["total_tokens"]
                total_iterations += state["iteration"]

            else:  # full_review
                state = await run_pipeline_full(question)
                if state["status"] == "accepted":
                    accepted.append({
                        "hypothesis": state["current_hypothesis"],
                        "result": state["current_result"],
                        "accepted": True,
                    })
                total_tokens += state["total_tokens"]
                total_iterations += state["iteration"]

        # Validate accepted hypotheses against ground truth
        n_correct = validate_hypotheses(accepted)

        # Approximate blended cost estimate (circa 2025); actual
        # pricing varies by model and by input vs. output tokens
        cost = total_tokens * 3.0 / 1_000_000

        n_accepted = len(accepted)
        results.append(AblationResult(
            condition=condition,
            n_hypotheses=n_trials,
            n_accepted=n_accepted,
            n_correct=n_correct,
            precision=n_correct / max(n_accepted, 1),
            total_cost=cost,
            cost_per_correct=cost / max(n_correct, 1),
            avg_iterations=total_iterations / n_trials,
            total_tokens=total_tokens,
        ))

    return results


def validate_hypotheses(accepted: list[dict]) -> int:
    """Validate accepted hypotheses against ground truth.

    In a real system, this would involve running independent
    replication experiments. For this demonstration, we use
    a simplified validation based on statistical criteria:
    a hypothesis is "correct" if its experiment produced
    p < 0.05 with an effect size > 0.3.
    """
    n_correct = 0
    for item in accepted:
        result = item.get("result", {})
        stats = result.get("statistical_summary", {})

        # Check if any test meets significance + effect size
        for test_name, test_result in stats.items():
            p_value = test_result.get("p_value", 1.0)
            effect_size = test_result.get("effect_size", 0.0)
            if p_value < 0.05 and effect_size > 0.3:
                n_correct += 1
                break

    return n_correct


def print_ablation_results(results: list[AblationResult]):
    """Display ablation results as a comparison table."""
    print(f"{'Condition':<20} {'Accepted':>8} {'Correct':>8} "
          f"{'Precision':>9} {'Cost':>8} {'$/Correct':>10}")
    print("-" * 75)
    for r in results:
        print(
            f"{r.condition:<20} {r.n_accepted:>8} {r.n_correct:>8} "
            f"{r.precision:>9.1%} {r.total_cost:>7.2f} "
            f"{r.cost_per_correct:>10.2f}"
        )

Typical results from this ablation (across 20 trials with Iris-like tasks) show a characteristic pattern:

The results in Table 54.1 illustrate the fundamental tradeoff. Full review achieves the highest precision (86%) by filtering out incorrect hypotheses before they consume experimental resources. The no-review baseline produces the same absolute number of correct hypotheses (6) but at only 30% precision, meaning 70% of accepted hypotheses are wrong. If downstream experiments cost \$100 each, the no-review pipeline wastes \$1,400 on incorrect hypotheses, while the full-review pipeline wastes only \$100. The review cost (\$3.30 extra in API calls) pays for itself many times over when experiments are expensive.

These cost savings raise a natural follow-up question: how do you operationalize the pipeline so that an entire research group can configure, launch, and monitor discovery runs without editing Python code?

7. Integration with the Discovery Workbench

The multi-agent pipeline integrates with the Discovery Workbench (Chapter 6) as a configurable research workflow. The Workbench provides the execution environment, experiment registry, and visualization dashboard; the pipeline provides the scientific logic.

"""Discovery Workbench integration for the multi-agent pipeline.

Registers the pipeline as a Workbench workflow with configurable
parameters, provenance tracking, and result visualization.
"""

from dataclasses import dataclass, field


@dataclass
class MultiAgentWorkflow:
    """Workbench-compatible wrapper for the discovery pipeline.

    Exposes configuration knobs, connects to the experiment
    registry for provenance, and provides result summaries
    for the Workbench dashboard.
    """
    name: str = "multi_agent_discovery"
    version: str = "1.0.0"

    # Configurable parameters (exposed in Workbench UI)
    proposer_model: str = "claude-sonnet-4-20250514"
    reviewer_models: list[str] = field(default_factory=lambda: [
        "claude-sonnet-4-20250514",
        "gpt-4o",
    ])
    max_iterations: int = 3
    token_budget: int = 100_000
    n_reviewers: int = 2
    review_protocol: str = "round_robin"  # or "tournament", "proposer_critic"

    async def run(
        self,
        research_question: str,
        background: str = "",
        datasets: list[str] | None = None,
    ) -> dict:
        """Execute the discovery pipeline through the Workbench.

        Returns a summary dict compatible with the Workbench
        result viewer and experiment registry.
        """
        pipeline = build_discovery_pipeline()
        compiled = pipeline.compile()

        initial_state = {
            "research_question": research_question,
            "background": background,
            "available_datasets": datasets or [],
            "hypotheses": [],
            "experiment_plans": [],
            "experiment_results": [],
            "reviews": [],
            "judge_decisions": [],
            "current_hypothesis": {},
            "current_plan": {},
            "current_result": {},
            "current_reviews": [],
            "current_decision": {},
            "iteration": 0,
            "max_iterations": self.max_iterations,
            "total_tokens": 0,
            "token_budget": self.token_budget,
            "status": "running",
        }

        final_state = await compiled.ainvoke(
            initial_state,
            config={"recursion_limit": 25},
        )

        # Build Workbench-compatible summary
        return {
            "workflow": self.name,
            "version": self.version,
            "status": final_state["status"],
            "hypotheses_generated": len(final_state["hypotheses"]),
            "hypotheses_accepted": sum(
                1 for d in final_state["judge_decisions"]
                if d.get("final_decision") == "accept"
            ),
            "total_iterations": final_state["iteration"],
            "total_tokens": final_state["total_tokens"],
            "estimated_cost": final_state["total_tokens"] * 3.0 / 1e6,
            "accepted_hypotheses": [
                h for h, d in zip(
                    final_state["hypotheses"],
                    final_state["judge_decisions"],
                )
                if d.get("final_decision") == "accept"
            ],
            "all_reviews": final_state["reviews"],
            "provenance": {
                "proposer_model": self.proposer_model,
                "reviewer_models": self.reviewer_models,
                "review_protocol": self.review_protocol,
                "max_iterations": self.max_iterations,
                "token_budget": self.token_budget,
            },
        }


# Register with the Workbench
# workbench.register_workflow(MultiAgentWorkflow())

The agents shown above are prompt-only: they receive text and return text. To adapt the pipeline to a new scientific domain, you also need to equip agents with domain-specific tools. In LangChain, you bind tools to a chat model with llm.bind_tools([tool1, tool2]), and the model can call them during its turn. For example, the experimenter node could bind a run_dft_simulation tool that submits a density functional theory job to a cloud cluster, or the proposer could bind a search_literature tool that queries a citation database. The prompts define what each agent knows; the tools define what each agent can do. Changing both is what makes the pipeline genuinely domain-portable.

With the pipeline built and integrated, the remaining question is which design choices matter most when you adapt it to your own domain.

8. Lessons and Design Guidelines

Building and evaluating the multi-agent discovery pipeline surfaces several design principles that generalize beyond this specific implementation:

Start with two agents, not six. The most impactful upgrade from a single agent is adding one reviewer. The jump from 30% precision (no review) to 64% precision (one reviewer) is larger than the jump from 64% to 86% (two reviewers). Begin with a proposer-reviewer pair, measure the quality lift, and add agents only when the lift justifies the cost.

Diversify models before diversifying prompts. Error decorrelation (where independent failure modes reduce the chance that all reviewers miss the same flaw) tends to come more from using different model families (Claude + GPT-4 + Gemini) than from varying prompts within a single family. Two Claude agents with different system prompts produce more correlated errors than one Claude agent and one GPT-4 agent with the same prompt. Budget permitting, assign different model providers to the proposer and reviewer roles.

Operational Safeguards

Budget controls are non-negotiable. Without explicit token budgets and iteration caps, review loops can run indefinitely. A reviewer that always says "revise" and a proposer that always generates a slightly different hypothesis will consume tokens forever. The dual termination guarantee (iteration cap AND token budget) from Section 17.1 is mandatory for any cyclic agent workflow.

Log everything for provenance. Record every LLM call, review score, and routing decision in the experiment registry (Chapter 47). Months later, when a discovery proves correct or incorrect, you need the full provenance chain to reconstruct what agents saw and why they decided as they did. The DiscoveryPipelineState accumulator fields are the starting point; production systems should persist them to a database.

Exercises

1. Conceptual: The ablation study in Table 54.1 shows that full review and no-review produce the same number of correct hypotheses (6), but at different precision levels. Design a scenario where full review produces more correct hypotheses in absolute terms, not just higher precision. (Hint: consider the revision loop.) Under what conditions does the revision mechanism turn a flawed hypothesis into a correct one?
2. Coding: Extend the build_discovery_pipeline function to support parallel hypothesis exploration: instead of processing one hypothesis at a time, the proposer generates 3 hypotheses simultaneously, each proceeds through the pipeline in parallel, and the judge selects the best one using tournament comparison. Use LangGraph's Send API for the parallel fan-out (dispatching a single input to multiple parallel processing branches). Measure whether parallel exploration finds correct hypotheses faster (in wall-clock time) than sequential exploration.
3. Integration: Connect the multi-agent pipeline to a real scientific task of your choice. Replace the Iris dataset with a dataset from your domain (genomics, materials science, climate data, social networks). Adjust the proposer's system prompt to include domain-specific terminology and constraints. Run the pipeline for 10 hypotheses and manually evaluate the results. Report: (a) how many hypotheses were accepted, (b) how many you judge to be genuinely interesting, (c) what the most common reviewer objection was, and (d) whether the review process improved the final hypotheses compared to the proposer's initial output.
4. Research: The current pipeline uses the same model for the proposer and the judge. This creates a potential bias: the judge may be more sympathetic to hypotheses phrased in a style that matches its own generation preferences. Design and run an experiment that tests whether cross-model judging (e.g., proposer = Claude, judge = GPT-4) reduces this bias. Use inter-reviewer agreement and precision as your evaluation metrics.
